Balloons and drones and clouds; oh, my!

Sandia collects more precise weather, climate data with help from unmanned aerial system

Later this month, Sandia researchers will try flying a tethered balloon and an unmanned aerial system, colloquially known as a drone, together for the first time to get Arctic atmospheric temperatures with better location control than ever before. In addition to providing more precise data for weather and climate models, being able to effectively operate UASs in the Arctic is important for national security.

“Operating UASs in the remote, harsh environments of the Arctic will provide opportunities to harden the technologies in ways that are directly transferable to the needs of national security in terms of robustness and reliability,” says Jon Salton (6533), a Sandia robotics manger. “Ultimately, integrating the specialized operational and sensing needs required for Arctic research will transfer to a variety of national security needs.”

UP, up and away — Dari Dexheimer prepares a tethered balloon for the first joint balloon-unmanned aerial system test in May at Sandia/New Mexico’s Burn Site. (Photo by Randy Montoya)

Information on temperature of the atmosphere is critical for predicting the weather, monitoring severe weather, and improving climate models. Unlike tethered balloons or weather balloons, UASs don’t require helium, a nonrenewable resource, and can take off with less preparation, thus they can be launched from more remote locations. Most airports already collect atmospheric temperature profiles twice a day but switching to UASs with distributed temperature sensors would be better because they would be reusable and could fly more frequently, says atmospheric scientist Dari Dexheimer (8863).

Sky-high research

Dari has regularly flown tethered balloons out of Sandia’s dedicated Arctic airspace on Oliktok Point, the northernmost point of Alaska’s Prudhoe Bay, since 2015. These 13-foot-tall balloons carry distributed temperature sensors to collect Arctic atmospheric temperature profiles, or the temperature of the air at different heights above the ground, among other atmospheric sensors. The test this August will be the first time Sandia has flown an octocopter in the sky above Oliktok Point.

“The UAS and the balloon really complement each other in that the UAS has a smaller flight time, but it’s much more spatially diverse. The tethered balloon can stay up for a long time, giving you a lot of data, but it’s not easily mobile,” says Dari. The balloon is blown by the wind, to the limits of the tether, but the UAS can be directed to precise GPS coordinates.

Earlier this summer, Dari and the UAS flight team, led by Diane Callow (6533), tested the joint UAS-balloon setup in Sandia/New Mexico. They overcame a series of technical challenges including figuring out how to best secure and reel out the four-football-field long distributed temperature sensor cable while making sure it doesn’t get tangled in the UAS’s rotors.

They also worked out the logistics of operating the balloon and the system at the same time. To avoid bumping into each other or tangling the cables, the balloon was tethered downwind and the UAS stayed at least 100 feet away from it.

Cool sensors for cool science

The distributed temperature sensor is an angel-hair-pasta thick fiber-optic cable. By seeing how light bends in the cable, Dari can calculate the temperature of that part of the cloud. This measurement has a resolution of one meter, and she sends a light pulse every 30 seconds. This gives Dari and climate modelers an unprecedented level of detail on the temperature profile of the atmosphere.

Dari Dexheimer and Mike Kuehl (6533) work on a radiosonde, or atmospheric sensor package, that will be carried on an unmanned aerial system aircraft as part of a joint balloon/UAS test.

In addition to the temperature sensor, the tethered balloon carries special supercooled liquid water sensors. Supercooled liquid water is pure water that remains a liquid below its freezing point because it has nothing to crystalize upon. It is important because clouds containing a lot of supercooled liquid water behave differently from normal clouds, sticking around for days and even acting like a blanket to warm the surface below. Better understanding of these kinds of mixed-phase clouds is important for more accurate climate models.

The sensors are vibrating wires upon which supercooled liquid water can freeze. As the ice builds up, the vibration slows, and this tells researchers how much supercooled liquid water is present in that part of the cloud. For the project’s next steps, the team hopes to add these supercooled liquid water sensors to a fixed-wing UAS and fly the UAS into the clouds. They hope to see how badly the UAS ices up, determine how to mitigate the effects of icing, and eventually collect useful data on cloud conditions with more spatial control than the balloon could get.

Both the cloud temperature and supercooled liquid water content can be compared between the UAS and the balloon as well as with data from ground-based Atmospheric Radiation Measurement sensors also at Oliktok Point. Sandia manages the ARM North Slope of Alaska site as part of the ARM Climate Research Facility, a national scientific user facility funded through DOE’s Office of Science.

Access to restricted airspace invaluable

“Our ability to run UASs as well as tethered balloon operations in the Arctic, and our ability to combine those measurements and computer modeling in innovative ways allows us to really put the Oliktok facility to use for the national security and science communities,” says Lori Parrott (8863), manager of atmospheric sciences.

Sandia is not the only institution using Oliktok Point to test UASs in extreme Arctic conditions; other institutions also fly UAS systems at Oliktok. For example, the University of Alaska Fairbanks’ Alaska Center for Unmanned Aircraft Systems Integration flew its UASs at Oliktok Point this summer, through a Cooperative Research and Development Agreement with Sandia. They have a testing facility at Toolik Lake about 130 miles south, but access to the restricted airspace Sandia manages over the Beaufort Sea at Oliktok is invaluable, says Lori.

Discussions are underway with other potential users across multiple federal agencies. Lori says, “The 700-mile-long restricted airspace that Sandia manages for DOE has strategic importance because it can allow scientists to conduct experiments and exercises over Arctic waters without risk to human-piloted aircraft. Flights for search-and-rescue exercises, data collection on ice or atmospheric conditions, or testing technology, would otherwise be very difficult to conduct.”

This project combining UASs and tethered balloons was supported by Sandia internal funding. The flight team includes Dave Novick, Dan Small, and Chris Wilson (all 6533). Dari’s Arctic team includes technologist Casey Longbottom (8863).

A video about flying tethered balloons in Oliktok Point is available here.
